Butterfly Wing Screw
50x Bolts, 50x Washers, 50x Nuts. Nylon bolts are non-magnetic
Made from tough, lightweight nylon, these fasteners offer excellent electrical insulating and non-corrosive properties
Please see the technical image illustration for size references. All measurements are in millimetres/millimeters.
Product Details:
- Size_Reference: M6 x 15mm.
- Colour_Reference: Natural.
- Material_Reference: Nylon / Polyamide 66.
- Type_Reference: Butterfly Screw.
- Quantity_Reference: 50.
- Pitch_(mm): 1.
Dimensions (L x W x D mm):
15 x 6 x 6.Additional Specifications:
- Washer_Dimension: Stock Code: CR06625PA66 , Material: Polyamide66 , Material Reference: PA66/W0 , Head/Drive Type: Flat washer , Overall Size: M6 , W0 A: 11.78 , W0 B: 6.51 , W0 T: 1.6 ,.
- Nut_Dimension: Stock Code: CR06438 PA66 , Material: Polyamide66 , Material Reference: PA66/HN , Head/Drive Type: Hexagon Nut , Overall Size: M6 , N (mm): M6 , HN B: 9.89 , HN H: 5.05 ,.
- Bolt_Dimension: Stock Code: CR06919PP , Material: Polypropylene , Material Reference: PP , Head/Drive Type: Butterfly Bolt Butter Fly Screw , Overall Size: M6 x 16 , Metric Size: M6 , D: 6 , Pitch: 1.0 , L: 16 , HH: 15.7 , TH: 8 , WL: 31.4 ,.
