Features:
- 2x fully threaded plastic rods. 4 nuts included. Material: PA66+GF / 30% Glass-Fibre Reinforced Nylon. Natural colour. Size: M6 x 500 mm. Diameter: 6 mm. Pitch: 1 mm. SKU: 980.
- Made from 30% glass-fibre-reinforced nylon (PA66+GF), providing greater stiffness and dimensional stability than unfilled PA66.
- Reinforced nylon is less flexible than unfilled PA66, so avoid repeated bending and check tightening method.
- The fully threaded 500 mm length can be used as supplied or cut carefully into custom reinforced plastic sections.
- Use for light-duty spacing, alignment and positioning where a reinforced plastic M6 threaded rod is useful.
Product Summary:
These natural M6 x 500 mm threaded rods are supplied as a pack of two and are made from 30% glass-fibre-reinforced nylon (PA66+GF). The glass-fibre reinforcement gives a stiffer plastic thread than unfilled PA66 and helps dimensions stay steadier during light spacing, alignment and cut-to-length work. This size suits slimmer reinforced spacers, alignment rods and cut-to-length plastic threaded sections, especially where a reinforced non-metallic threaded bar is useful but a metal rod is not preferred. The trade-off is reduced toughness under impact or repeated bending compared with unfilled nylon, so check the assembly, mating nuts and tightening method before use. Supplied with 4 nuts.
| Core Technical Details | |
|---|---|
| Product Type | Threaded Rods |
| Size (mm) | M6 x 500mm |
| Material | Nylon PA 66 / 30% Glass Fibre Reinforced |
| Colour | Natural |
| Quantity | 2 |
| Dimensions - mm | |
| Diameter -mm | 6.00 |
| Length - mm | 500 mm (L) |
| Width -mm | 6 mm (W) |
| Thickness / Depth -mm | 6 mm (D) |
| Pitch - mm | 1 |
| Dimensions - Inches Conversion | |
| Length -inches | 19.685 |
| Width -inches | 0.236 |
| Thickness / Depth -inches | 0.236 |
| Pitch - inches | 0.039 |
| Product Download Sheets | |
| Safety Data Sheet | Conformity Safety |
| Material Data Sheet | Nylon PA66 30% Glass Fibre — Material Datasheet |
| Product Data Sheet | Nylon PA66 30% Glass Fibre — Threaded Rods Datasheet |
| Type | |
|---|---|
| Technical Drawing | https://caterpillar-red.com/content/Technical_Drawings/A-Technical-Drawing-Threaded-Rod-Stud.jpg |
| Bolt Dimensions | Stock Code: CR-Rod-07029-PA66GF Material: Nylon PA66 + 30% Glass Fibre Reinforced Material Reference: PA66+GF Head/Drive Type: Fully Threaded Rod size: M6 x 500 D: 6 mm Pitch: 1.0 mm L: 500 mm |
| Width -mm | 6 mm (W) |
| Length - mm | 500 mm (L) |
| Thickness / Depth -mm | 6 mm (D) |
| Diameter -mm | 6.00 |
