5x White PP Hex Head Plastic Screws & Bolts M16 x 65 mm, Nuts & Washers

5x White PP Hex Head Plastic Screws & Bolts M16 x 65 mm, Nuts & Washers

The details, at a glance.

  • Thread M16
  • Length 65 mm
  • Material PP / Polypropylene
  • Colour White
  • Pack size 5
Prices
Price per pack €19.56 ex VAT · €23.47 inc VAT
Current Stock:

    Adding to basket… Added to your basket.
    Request a quote

    In stock

    Need another length?

    65 mm150 mm

    Dimensions & documents

    Conformity Safety Polypropylene (PP) — Material Datasheet Polypropylene (PP) — Screws & Bolts Datasheet Technical drawing

    Check the fit. Technical specification

    Product type
    Hex Head Bolts
    Size (mm)
    M16 x 65mm
    Thread
    M16
    Material
    PP / Polypropylene
    Colour
    White
    Pack size
    5
    Diameter
    16.00 mm
    Length
    65 mm
    Width
    16 mm
    Thickness / depth
    16 mm
    Pitch
    2 mm

    Bolt, nut and washer dimensions

    Bolt

    Head/Drive Type: Hexagon Head Bolt, size: M16 x 65, D: 16 mm, Pitch: 2 mm, L: 65 mm, HD: 23.58 mm, HH: 10 mm

    Nut

    Material: Polypropylene, Head/Drive Type: Hexagon Nut, size: M16, N (mm): M16, HN B: 23.84 mm, HN H: 14.45 mm

    Washer

    Material: Polypropylene, Head/Drive Type: Flat washer, size: M16, W0 A: 29.74 mm, W0 B: 17.14 mm, W0 T: 3 mm

    Description

    Features

    • 5x Bolts, 5x Nuts, 5x Washers. Pantone White 11-0601-TCX. Material: PP. Type: Hex Head Bolts. Length: 65mm. Diameter: 16mm. Pitch: 2mm. Across flats: 23.5mm. Head height: 10mm. SKU: 671.
    • Polypropylene is renowned for its high strength-to-weight ratio, inherent flexibility, and moderate resistance to impact.
    • Polypropylene has good chemical resistance over a wide range of bases and acids, as well as most solvents. It is very resistant to absorbing moisture.
    • These lightweight, non-corroding, insulating fixings are suited to chemical and wet environments, electrical enclosures and general assembly where metal would rust or react.
    • The hex head sits above the surface for access during fitting, removal and refitting. Also known as hex bolts, hexagon head screws.

    Product Summary

    Pack of 5 white polypropylene hex head bolts, M16 x 65 mm, with 5 nuts and 5 washers. Thread pitch: 2 mm. Polypropylene has good chemical resistance over a wide range of bases and acids, as well as most solvents. It is an economical, lightweight material with a high strength-to-weight ratio, inherent flexibility and moderate impact resistance. Polypropylene is very resistant to absorbing moisture and is a good electrical insulator. The material is non-corroding. Hex head bolts are also known as plastic bolts or plastic screws.
